Roland JUNO Stage Voice Expandable Synthesizer with Song Player

Roland JUNO Stage Voice Expandable Synthesizer with Song Player

A New Synth Star for the Stage!

Designed from the ground up for live performers, JUNO-STAGE is a new breed of synthesizer that every gigging keyboardist will love. Decked out with an extra-large display, USB backing-track functionality, a Click output for drummers, dedicated performance knobs, hands-free patch select, instant master MIDI control functionality, and much more, JUNO-STAGE sets a new standard for powerful onstage performance at a friendly price.

- High-quality, versatile sound set, including 88-key stereo multi-sampled piano plus dual SRX expansion bay
- Newly developed 76-note keyboard with first-class touch and response
- Live-performance features such as an extra-large LCD, dedicated Reverb and Master EQ knobs, Click Output for drummers, and hands-free patch-select footswitches
- USB port enables accompaniment-track playback (MP3, WAV, AIFF, SMF) directly from USB key
- Phantom powered mic input plus reverb, great for playing and singing along
- MIDI Controller mode transforms JUNO-STAGE into a MIDI master keyboard with a single touch

Keyboard
• 76 keys (with velocity)

Sound Generator
Maximum Polyphony
• 128 voices
Parts
• 16 parts
Wave Memory
• 128MB (16-bit linear equivalent)
Preset Memory
• Patches: 1027 + 256 (GM2), Rhythm Sets: 32 + 9 (GM2), Performances: 64
User Memory
• Patches: 256, Rhythm Sets: 32, Performances: 64
Effects
• MFX: 3 systems, 79 types, Chorus: 3 types, Reverb: 5 types, Mic Input, Reverb: 8 types

Song Player
File Format
• SMF: format-0/1, Audio File: WAV/AIFF/MP3

Other
Arpeggiator
• Preset: 128, User: 128
Rhythm Pattern
• Preset: 256 (26 groups), User: 256 (32 groups)
Chord Memory
• Preset: 64, User: 64
Controllers
• D BEAM Controller, Pitch Bend/Modulation Lever, S1/S2 Switches, Sound Modify Knob x 7
Display
• 240 x 64 dots graphic LCD (with backlit)
Expansion Slots
• SRX expansion board: 2 slot
External Storage Device
• USB MEMORY (supports USB 2.0 Hi-Speed Flash Memory)
Connectors
• Headphone Jack, Song/Click Out Jack, Output Jacks (L (MONO), R): 1/4 inch phone type, Mic Input Jack: 1/4 inch phone type or XLR type (phantom power), EXT INPUT Jack: stereo miniature phone type, MIDI Connectors (IN, OUT), Hold Pedal Jack, Control Pedal Jack, Patch Select Jack, USB Connector (MIDI)

Power Supply
• DC 9 V (AC Adaptor)
Current draw
• 2,000 mA
Accessories
• Owner's Manual, CD-ROM x 2 (Sound Editor, Playlist Editor, Librarian, USB MIDI driver, SONAR LE), Music Player Pad, Music Player Cable, USB Memory Protector, AC Adaptor

Size and Weight
Width (W)
• 1,251 mm
Depth (D)
• 344 mm
Height (H)
• 112 mm
Weight
• 9.8 kg
