Focusrite Saffire PRO 14 interface

Focusrite Saffire PRO 14

Focusrite Saffire Pro 14
• 6 inputs
• 8 outputs
• Midi In / Out
• FireWire
• Headphone Output
• Automatic microphone signal / line
• Switch: Line / Instrument via Saffire MixControll Application
• Switch: + 16dBu / -10dBV gain inputs 3, 4 by Saffire MixControll Application
• Switch 48V phantom power on channels 1 and 2

• Microphone inputs (1, 2):
- Frequency response: 20Hz - 20kHz
- Gain: + 13dB - 60dB +
- THD: 0.001%
- Input impedance: 2k Ohm

• Inputs instrumental (1, 2):
- Frequency response: 20Hz - 20kHz
- Gain: + 13dB - 60dB +
- THD: 0.004%

• Line inputs (1, 2):
- Frequency response: 20Hz - 20kHz
- Gain: -10dB - + 36dB
- THD: 0.001%
- Input Impedance:> 10k Ohms

• Line inputs (3, 4):
- Frequency response: 20Hz - 20kHz
- Gain: + 16dBu / -10dBV
- THD: 0.003%
- Input Impedance:> 10k Ohms

• Analog outputs (1-4):
- THD: 0.001%
- Maximum Output Level: + 10dBu
- Electronically balanced

• Signal processing:
- A / D:> 109dB
- D / A:> 106dB
• Sampling: 44.1kHz, 48kHz, 88.2kHz, 96kHz

• Dimensions: 215x45x220mm
• Weight: 1.5kg
