Focusrite RedNet 4 8-channel remote controlled microphone preamp

Focusrite RedNet 4

RedNet 4 adds eight of the latest remote-controlled Focusrite mic preamps / line inputs to your RedNet system through a single Ethernet cable. With two selectable DI’s, RedNet 4 provides an effective range of analogue inputs for your system. The unit includes Focusrite’s world-class precision A-D conversion. Mic/Line/DI selection, gain, phantom power, HPF and metering are also accessible from the front panel. The benefit of remote control microphone pre-amp gain is that you can keep the mic pre close to the source (so the analogue cable run is minimal) while still setting gain stages from the control room.

Features:

• Eight high-quality Focusrite 'RedNet' mic preamps
• DC-coupled signal path for characteristically open and transparent sound
• Selectable line and DI inputs for input flexibility
• Remote-controllable Gain, Phantom Power and High-Pass Filter from Yamaha CL and QL Series Consoles.
• Dynamic range: 119dB
• THD+Noise: <0.001%
• Mic input Level up to +16dBu
• Max mic input gain: 63dB
• JetPLL jitter-reduction technology
• Comprehensive remote control software with powerful graphic user interface

Specifications:

• 8 Focusrite mic preamps and line/DI inputs
• 8 XLR microphone inputs
• 8 Line inputs (DB25)
• TRS-DI inputs for channel 1 and 2 in the front panel
• Dynamic range: 120 dB
• Microphone input level up to +16 dBu
• JetPLL jitter reduction technology
• Up to 24-bit/192kHz
• 48V phantom power
• Dante Ethernet port for RedNet PCIe card
• Design: 19"/ 2U
