Palmer PAN 02 PRO active di-box

Palmer PAN 02 PRO

• Standard active DI box.
• Can be operated with 9 V batteries or 48 V phantom power.
• High-impedance input; higher output level than with a passive DI box.
• Active circuitry allows for high input impedance ( 1 meg. ohm) and higher input sensitivity (typical difference between in and out -4 dB).
• Maximum output impedance with phantom power operation +10 dB.
• Output: transformer balanced.
• The special "floating ground" circuitry enables ground lift even during phantom power operation.
• Metal case 110 x 73 x 42 mm.
