M-Audio M-Track Plus II – Two-Channel USB 2.0 Audio Interface w/ 24-bit/96 kHz Resolution w/ Cubase LE

M-Audio M-Track Plus II

The M-Track Plus delivers studio-grade 24-bit/96 kHz audio resolution in a compact and friendly format that is ideal for any user. This versatile interface accommodates any input, from an electric guitar to a professional condenser mic—and phantom power is provided. Ideal for on-the-go musicians, the sleek M-Track Plus features a durable metal case to withstand the rigors of the road. A single USB cable provides both power and a data connection to and from your laptop or desktop computer. Completing this powerful package are three complementary software selections: Cubase LE; Ableton Live Lite; and Waves Audio plugins to get things started.

Features
• Pro-grade audio recording with up to 24-bit/96 kHz resolution
• Solid metal chassis and low profile design
• Dedicated Channel Line/Instrument controls for receiving line-level signals and plugging in instruments directly
•(2) XLR+1/4” combo inputs with phantom power for recording vocals, guitars, bass, and more
• Channel-specific LED VU meters provide real-time visual feedback of the audio signal
• Zero-latency monitoring with USB/Analog Direct Balance control
•(2) Balanced 1/4” main outputs with dedicated level control
• Headphone out with independent level control for private recording and mixing
• USB-powered connectivity and solid metal construction for on-the-go use
• Includes Ableton Live Lite and Cubase LE for recording, mixing, and producing music with your Mac or PC
• Use the included Waves plugin bundle (AudioTrack, Eddie Kramer Effect Channel, and TrueVerb) to add a professional finish to your production

Specifications
• Mic Inputs 1–2 (balanced XLR)
• Frequency Response: 20 Hz – 20 kHz (+/-0.1 dB)
• Dynamic Range: 104 dB (A-weighted)
• Signal-to-Noise Ratio: 104 dB (1 kHz, +1.4 dBu, A-weighted)
• THD+N: 0.003% (1 kHz, +2 dBu input, -0.8 dBFS)
• Preamp EIN:
-133 dBu (max gain, 40 Ω source, A-weighted)
-126 dBu (max gain, 150 Ω source, unweighted)
• Sensitivity: -53 dBu
• Gain Range: 55 dB
• Line Inputs 1–2 (balanced 1/4" [6.35 mm] TRS)
• Frequency Response: 20 Hz – 20 kHz (+/-0.1 dB)
• THD+N: 0.022% (1 kHz, -1 dBFS)
• Sensitivity: -43dBu
• Gain Range: 55 dB
• Inst Input 1 and 2 (unbalanced 1/4" [6.35 mm] TS)
• Frequency Response: 20 Hz – 20 kHz (+/-0.1 dB)
• THD+N: 0.022% (1 kHz, -1 dBFS)
• Sensitivity: -47 dBu
• Input Impedance: 1 MΩ
• Gain Range: 55 dB
• Main Outputs, L and R (impedance-balanced 1/4" [6.35 mm] TRS)
• Frequency Response: 20 Hz – 20 kHz (+/-0.3 dB)
• Dynamic Range / Signal-to-Noise Ratio: 102 dB (A-weighted)
• THD+N: 0.008% (1 kHz, -1 dBFS)
• Max Output Level: +2.86 dBu
• Power: USB bus-powered
• Size (H x W x D): 2.07 x 9.4 x 4.85 inches (52.58 x 238.76 x 123.19 mm)
• Weight: 2.29 lbs (1.04 kg)
