Sennheiser EK100 G3 Wireless Camera-Mount Receiver

Sennheiser EK100 G3

The Sennheiser EK 100 G3 is a lightweight camera-mount receiver that features an all-metal housing. The unit has 1680 tunable UHF frequencies and synchronizes with G3 transmitters at the touch of a button. A 3.5mm audio output will provide clean output signal using the included adapter cables. The receiver operates on 2 standard AA batteries, and an optional 12 VDC adapter is also available. The included shoe-mount adapter allows you to mount the receiver on a camera for convenient portable use.

Features:

• Sturdy metal housing
• 42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception
• Enhanced frequency bank system with up to 12 compatible frequencies
• Adaptive-diversity reception for high reception quality
• Pilot tone squelch for eliminating RF interference when transmitter is turned off
• Automatic frequency scan feature searches for available frequencies
• Enhanced AF frequency range
• Wireless synchronization of transmitters via infrared interface
• User-friendly menu operation with more control options
• Illuminated graphic display
• Auto-Lock function avoids accidental changing of settings
• HDX compander for crystal-clear sound
• Operates on 2 standard AA batteries
• Receiver features battery indication in 4 steps
• Contacts for recharging BA 2015 accupack directly in the receiver
• Wide range of accessories adapts the system to any requirement

Specifications:

• Frequency range: 516 ... 865 MHz
• The number of carriers: max. 1680
• The number of presets: 12
• The width of the frequency range 42 MHz
• The signal / noise ratio:> 110 dB (A)
• Frequency response: 25 - 18000 Hz
• Audio output power: 12 mW (32 Ohm)
• Audio-XLR connector and 3.5 mm jack
• Supply voltage: 2 x 1.5V AA
• Operating time: 6 - 10 hours.
• Dimensions: 82 x 64 x 24 mm
• Weight: 160 g
