Keeley Red Dirt Overdrive Mini

The four modes of operation are completely new for the Red Dirt Mini. The pedal's base-line tone is configured by taking the bottom plate off and adjusting the DIP switches. These switches allow you to change the clipping diodes which give you either a more compressed sound, or give you a more open tube-amp like sound and variations in between. The different overdrive styles are: Distortion, Overdrive, Crunch, and Amp. Going from the high gain Distortion Mode where you have 2 to 3 times screamer gain, they give you progressively cleaner, more open and bolder sounds. The Red Dirt Mini is huge on tone and flexibility.

- overdrive effects pedal
- 4 modes (Distortion, Overdrive, Crunch and Amp)
- true bypass
- controls for Drive, Tone and Level
- 2 Internal switches for selecting between modes
- Metal housing
- Status LED
- Bypass footswitch
- 6.3 mm mono IN/OUT jacks
- power supply optional 9V DC adapter 2.1 mm x 5.5 mm barrel plug, polarity (-) center
- battery operation not supported
- current draw 7mA
- dimensions (D x W x H) 92 mm x 47 mm x 50 mm
- weight 144 g
- made in USA
